  • High-quality Flame Retardant insulation piercing connector for secure electrical connections

TTD Series Flame Retardant Insulation Piercing Connector

1.Main line:Insulated copper or aluminum

2.Branch line:Insulated copper or aluminum

3.Live-line work or power-cut work is allowable

4.Main body of connector is made of flame retardant high strength insulating material that anti mechanical change or climatic variation.

5.The screw that is equipped with fastening torque nut is anti-corrosion treated,the torque nut enables the installation to be much simple,safe and quick,its constant puncturing pressure guarantees best electrical effect for the cable.

6.The connector is featured with property of waterproof,it is able to withstand voltage of 6kV in water without breakdown phenomenon.

7.The waterproof sealing end cap of branch line prevents water from entering into the branch connected conductor.It can be branched on the left or right side according to the demand.

Add to Quote
Inquiry Now

Share us on:

Share on facebook
Share on twitter
Share on linkedin
Share on pinterest
Share on skype
Share on telegram
Share on xing
Share on whatsapp
Share on email
Share on print

Description

TTD Series Flame Retardant Insulation Piercing Connector

When it comes to ensuring the safety and reliability of electrical connections, our Flame Retardant Insulation Piercing Connector is the ideal choice. Designed to meet the highest standards of performance and safety, this connector is perfect for a wide range of applications. These include residential, commercial, and industrial electrical systems.

Our Flame Retardant Insulation Piercing Connector is crafted from high-quality materials. This ensures excellent durability and longevity. The flame retardant properties mean the connector can withstand high temperatures. As a result, it reduces the risk of fire hazards, making it a crucial component in safety-conscious electrical installations. Learn more about UL 94, the Standard for Safety of Flammability of Plastic Materials.

Type Equivalent Applicable Conductor Max Current (A) Bolt Torque Nut
Main (mm2) Tap (mm2) Number (Pcs) Height (mm)
FN041FVO TTD041FVO 6-35 1.5-10 86 1 x M8 13 F1309
FN051FVO TTD051FVO 16-95 1.5-10 86 1 x M8 13 F1309
FN101FVO TTD101FVO 6-50 2.6(6)-35 200 1 x M8 13 F1309
FN151FVO TTD151FVO 25-95 2.6(6)-35 200 1 x M8 13 F1314
FN201FVO TTD201FVO 35-95 25-95 377 1 x M8 13 F1318
FN251FVO TTD251FVO 50-150 25-95 377 1 x M8 13 F1314
FN271FVO TTD271FVO 35-120 35-120 377 1 x M8 13 F1314
FN281FVO TTD281FVO 50-185 2.5(6)-35 200 1 x M8 13 F1314
FN401FVO TTD401FVO 50-185 50-150 504 2 x M8 13 F1318
FN431FVO TTD431FVO 70-240 16-95 377 2 x M10 17 F1720
FN441FVO TTD441FVO 95-240 50-150 504 2 x M10 17 F1725
FN451FVO TTD451FVO 95-240 95-240 530 2 x M10 17 F1725
FN551FVO TTD551FVO 120-400 95-240 679 2 x M10 17 F1737



Key Features and Benefits of Flame Retardant IPC:

  1. Superior Safety: The flame retardant materials help prevent the spread of fire, offering enhanced safety in critical applications.
  2. Reliable Performance: Our connector ensures minimal resistance and optimal conductivity for a secure and efficient electrical connection.
  3. Easy Installation: The design allows for quick and straightforward installation, saving time and effort on the job.
  4. Versatile Application: Suitable for various types of electrical systems, it can be used in both new installations and retrofit projects.

Whether you are an electrical contractor, a maintenance technician, or a DIY enthusiast, our Flame Retardant Insulation Piercing Connector is an excellent addition to your toolkit. It not only enhances the safety of your electrical connections but also ensures long-lasting performance.

Why Choose our Flame Retardant IPC:

  • Quality Assurance: We prioritize quality to meet and exceed industry standards.
  • Customer Support: Our dedicated team is here to assist with any questions or concerns.
  • Global Shipping: We offer reliable shipping options to deliver our products to your location promptly.

Invest in our Flame Retardant Insulation Piercing Connector today. Experience the peace of mind that comes with using a high-quality, reliable product. Order now and take advantage of our competitive pricing and fast shipping options.

Upgrade your electrical systems with our Flame Retardant Insulation Piercing Connector. Ensure the highest level of safety and performance. Browse our range of Insulation Piercing Connector for more options and place your order today!
